Survivability

The C-27J has outstanding threat avoidance capabilities, including a take-off ground run of about 1,900 feet at maximum take off weight on an unpaved surface. In a tactical environment, the aircraft is capable of climbing to 10,000 ft in 3 minutes, descending from 10,000 ft in under 2.5 minutes and can handle up to 3.0g forces. At maximum landing weight, the C-27J has a ground roll of less than 1,115 ft.

Designed for harsh operations, the C-27J Spartan features redundant systems, Mil-spec designs, and built-in self protection provisions. The aircraft can also support a multitude of aircraft survivability equipment ensuring commonality with existing force requirements.

• Damage Tolerance:
  • All critical systems are redundant (hydraulic, electrical, ADS, avionics, displays, controls)
  • Three-spar construction
  • Oxygen for crew and cargo hold in case of depressurization
  • Fuel jettison capability
  • OBIGGS, anti-deflagration fuel tanks
• High Power-to-Weight Ration:
  • Rapid acceleration/deceleration
  • Rapid climb capability
  • High speed capability with rear ramp down (180 kts) or with the aircraft just above ground level (260 kts)
• Superior Tactical Maneuverability:
  • Low stall speed (80 to 90 kts)
  • Low level flight to avoid detection
  • High roll rate
  • Tight turn radius
• Excellent visibility through 16 cockpit windows
